Product Overview

Product Overview

Thermally conductive silicone potting compound, curing at room temperature, and fast curing by the heating.

Product Applications

suitable for electronic products such as power supply module, control units in electric vehicle, high power control modules in hydrogen fuel cell.
Product Features

Good self-leveling

Low viscosity, good self-leveling, iMPact resistance.

High thermal conductivity

High thermal conductivity, flame retardant.

Waterproof, moisture-proof, and weather resistant

Waterproof grade IP65, good resistance to low and high temperature , working temperature from -50℃ to 200℃, effectively extend the service life of electronic and electrical.
Product List
Product Model Color Mixing Ratio Viscosity Hardness Cure Mechanism Thermal Conductivity More Parameters
AS42 Gray 1:13500±1000 mPa.s
@ 25℃		55±3
Shore A		2~3h Initial Curing Time @ 25℃
24h Complete Curing Time @ 25℃
30min Complete Curing Time @ 80℃		0.7W/m·K Detailed introduction
AS42(00) Light grey 1:16000±1000 mPa.s
@ 25℃		65±10
Shore 00		4~6h Initial Curing Time @ 25℃
24~48h Complete Curing Time @ 25℃
20~30min Complete Curing Time @ 80℃		2.5W/m·K Detailed introduction
AS42(10) Grey 1:13500±1000 mPa.s
@ 25℃		45±5
Shore A		3~5h Initial Curing Time @ 25℃
24h Complete Curing Time @ 25℃
30min Complete Curing Time @ 80℃		0.7W/m·K Detailed introduction
AS42(10)L Gray 1:13500±1000 mPa.s
@ 25℃		45±5
Shore A		3~6h Initial Curing Time @ 25℃
24h Complete Curing Time @ 25℃
30min Complete Curing Time @ 80℃		0.7W/m·K Detailed introduction
AS42(11) Gray 10:13000±1000 mPa.s
@ 25℃		55±5
Shore A		4~6h Initial Curing Time @ 25℃
168h Complete Curing Time @ 25℃		0.7W/m·K Detailed introduction
AS42(16) Grey 1:13000±1000 mPa.s
@ 25℃		65±10
Shore 00		4~6h Initial Curing Time @ 25℃
24~48h Complete Curing Time @ 25℃
30min Complete Curing Time @ 80℃		1.6W/m·K Detailed introduction
AS42(35) Pink 1:112500±2500 mPa.s
@ 25℃		25±5
Shore A		3~5h Initial Curing Time @ 25℃
24h Complete Curing Time @ 25℃
20~30min Complete Curing Time @ 80℃		3.8W/m·K Detailed introduction
