Thermally conductive silicone gap filler, formed with the shape of the structure, with excellent structural applicability and surface conformability characteristics of structural parts, and sufficient gap filling. With good insulation withstand voltage characteristics and temperature stability, safe and reliable.
Applied to the heat sink bottom or frame, high speed hard drive, micro heat pipe heat sink, automotive engine control device, semiconductor automatic testing equipment. Widely used in telecommunication equipment such as network terminal, storage equipment, LED display backlight tube, consumer electronics power devices, security equipment, instruments, electrical, automotive electronics and other industries.
Product Model | Color | Mixing Ratio | Viscosity | Hardness | Condition | Temperature | Thermal Conductivity | More Parameters |
---|---|---|---|---|---|---|---|---|
AS32(03) | White | N/A | 250000±50000 25℃ | 60±5 Shore 00 | 20~30min 100℃ | -50~200℃ | 3.1W/m·K | Detailed introduction |
AS42(02) | Light grey | 1:1 | Paste | 50±10 Shore 00 | 24~48h/25℃ 20~30min/80℃ | -50~200℃ | 2.0W/m·K | Detailed introduction |
AS42(04) | Khaki | 1:1 | Paste | 60±10 Shore 00 | 24~48h/25℃ 20~30min/80℃ | -50~200℃ | 4.0W/m·K | Detailed introduction |
