Ancham technology of adhesives helps our customers meet some of the more complex challenges

Product Overview

Product Overview

One-component, fast curing by heating, with extremely high bonding strength and mechanical strength, excellent temperature resistance, chemical resistance.

Product Applications

Used for bonding and fixing, sealing protection, device protection, etc. of electronic product parts and structural parts.
Product Features

Fast Curing

Fast Curing, Heating curing.

High bonding strength

High bonding strength, excellent reliability.

High Strength

As Ancham's flagship product, it can greatly meet a wide range of requirements for electronics manufacturing, including the production of ultra-thin and large-size PCBs.
Product List
Product Model Color Hardness Viscosity(cps) Curing Type Lap Shear Strength Steel(grit blasted) Shelf Life More Parameters
AE1101 Black 80±5D20000±5000
25℃		5~10min/
80℃		≥20MPa6 months/-5~-10℃ Detailed introduction
AE1102 Black 80±5D15000±5000
25℃		5~10min/
80℃		≥15MPa6 months/-5~-10℃ Detailed introduction
AE1115 Black / White 85D60000~8000030min/150°C20MPa6 months/2-8°C Detailed introduction
AE1151 Black 83±5D85000±10000
25℃		60min/100℃18~20MPa6 months/-5~-10℃ Detailed introduction
AE1152 Black 83±5D105000±10000
25℃		60min/100℃18~20MPa6 months/-5~-10℃ Detailed introduction
AE1180 Black / White 80D60000~8000020min/80°C15MPa6 months/-5~-10℃ Detailed introduction
AE1181 Black Gray 80±5Paste20~30min/
150°C		23~25MPa6 months/-5~-10℃ Detailed introduction
AE1182 Black Gray 80±5DPaste20~30min/
150°C		18~20MPa6 months/-5~-10℃ Detailed introduction
AE1380 White 85±5D15000±5000
25℃		15~20min/
130℃		≥20MPa6 months/-5~-10℃
15 days/15~20℃		 Detailed introduction
